A 1998 Jeep Grand Cherokee ZJ Limited Sport Utility 4D build by @JeepZJ2.0

1998 Jeep Grand Cherokee ZJ Limited V8. D30 & D44 w/upcountry tow package. Building an overland style go anywhere ZJ, importantly multi purpose high clearance for Storms/flooding bug out vehicle to the mountains

1998 Jeep Grand Cherokee ZJ Limited Sport Utility 4D

Build Details


  • 5.2L 318CI V8 Magnum Engine
  • Flow-Kooler water pump/180* Thermostat
  • Jeep Cables Big 7 2G
  • Optimum Battery
  • Hayden 2791 Premium Fan Clutch
  • MOPAR 52079654AE Cali. Plastic Radiator Fan Blade
  • SMP Blue streak Heavy Duty Ignition coil
  • SMP Blue Streak Ceramic 8.5mm spark plug wires
  • NTK O2 sensors
  • Billet Power Steering Pump Bracket


  • K&N Cold air Intake


  • IRO ZJ Long Arm Exhaust Kit
  • IRO muffler
  • Magnaflow high flow CAT


  • IRO 1/2" Heavy Duty OTK Steering
  • IRO - Tenecco DUAL Stabilizer Kit
  • IRO HD Slip Yoke Eliminator (NP231)(in progress)
  • IRO Steering Knuckle Light Brackets
  • Addco Front sway bar 1 1/8" w/poly grease fitted bushings
  • Addco Rear sway bar w/poly grease fitted bushings
  • Timkin Hubs
  • NP231: 99’ XJ
  • Teraflex upper & lower Ball joints
  • 4340 Chromoly Axle Shafts, upgraded Spicer 5-760X u-joints
  • Alloy USA Axle Tube Seal Kit
  • Tom Woods custom Rear Double Cardan drive shaft


  • Powerstop Z31 Calipers/Rotors/Pads

wheels & tires

  • BF Goodrich KM3 35x12.50r15
  • Pro Comp 69's 15x8



  • RC pod lights knuckles
  • Black oak ditch lights


  • Goliath off-road Front steel bumper
  • Goliath off-road Rear steel bumper
  • Cladding Delete
  • Z Notch Custom Flares


  • IRO Unibody Frame Stiffeners (Center Section)
  • IRO ZJ Belly Skid plate
  • Amsoil fluids
  • Marco train horn
