Ian Harkins
2003 Jeep Wrangler TJ Sport
More actions
Share
Comments
My build stared about 15 years ago and it doesn't look like it's going to be done anytime soon!
Show more
Save this build
Comment
Build highlights
37 parts
42" tires
Gray
Wheels
20" trailready beadlocks
42" Bfgoodrich red label crawlers
Suspension
Front 14" travel fox 2.0 coilovers
Rear 16" travel fox coilovers
Double triangulated 4 link front and rear
TK1 rear sway bar
Wide open design aluminum links
Exterior
Chris Durham hood
R.C.M. Fab custom boat sides and front fenders
R.C.M. Fab custom aluminum roof panel
Lighting
Rear light bar
All4offroad rock lights
Drivetrain
Nv3550 trans
Dana 300 tranfer case with lowmax 4:1 gear set and 32 spline output shafts
Northwest fab 2:72 black box
Front axle- Chevy kp Dana 60
Sunfireoffroad aluminum front hubs
Motobilt diff cover
5:38 Yukon gears
Yukon cromos 35 spline inner and outer with super joints
Yukon hardcore locking hubs
Rear axle- corporate 14 bolt
Sunfireoffroad aluminum rear hubs
Yukon grizzly locker
Brakes
Wilwood 6 piston front brakes
Wilwood 4 piston rear brakes
CNC rear cutting brakes
Dodge 1 ton master cylinder
Engine
Stock 4.0
Exhaust
Banks header
Custom exhaust with Magnaflow muffler
Intake
Custom intake
Interior
Custom roll cage
Corbeau ultra SS seats
Other
Factor 55 ultra hook
Factor 55 fair lead
S&W 7/16 winch rope
