Bob Ross TJ
2004 Jeep Wrangler TJ X 4WD 2dr 4x4
More actions
Share
Comments
I've been wheeling this Jeep since 2009 and bone stock. My friends at Rev Limit fab built the custom cage and did all the suspension and tons swap.
Show more
Save this build
Comment
Build highlights
43 parts
40" tires
White
Wheels
40 maxxis trepadors
17 inch TMI beadlocks
Suspension
14 inch Radflo 2.0 coilovers front
16 inch Radflo 2.0 coilovers rear
custom 3link front, 4 link rear with Barnes enduro joints
Radflo 2.0 4 inch bumps
Antirok sway bar
Trail Gear limit straps
Exterior
custom Revlimit Fab back half and cage
Barnes 4wd rocker guards
Lighting
Morimoto sealed7 led headlights
Rugged Ridge led cubes
truckstop led tail lights
Drivetrain
nv3550
np231
Ford HP D60 with dodge 33spline outer knuckles
D60 Spartan locker
Yukon cromos
Yukon super joints
Revolution 5.38 gears
Busted Knuckle ball joint eliminatiors
14 bolt welded
Barnes 4wd trusses and pinion guard
Brakes
stock dodge front
Lugnut 4x4 14 bolt disc brake conversion
stock master
Engine
stock 4.0L
Brown Dog motor mounts
Exhaust
modified stock
after cat dump out
Intake
custom Spectre
Interior
Mastercraft rubicon seats
Corbeau harnesses
Joes Racing lightweight steering wheel
Other
Motobilt fuel cell
Motobilt diff covers
9.0 Superwinch
Trail Gear double ended ram
PSC TJ power steering pump
Beyond Precise orbital
Speedway Motors reservoir
Griffin radiatior
Olivers driveshafts
