Bought the Jeep in March of 2019. I have custom made the front and rear bumpers. Finished my 1 ton swap and rear stretch in September 2021.

Build highlights

35 parts
40" tires
3" lift
Black

Wheels

Maxxis RZR MT's 40x13.5x17

Suspension

Evo 3" Plush Ride Front Spring

Factory JK Rear Springs

Synergy 8" Spring Stretch

Fox 2.0 shocks with Resi's

JCR Track Bars Front and Rear

Artec Aluminum Front 3-link

Evo Manufacturing Air Bump Stops Front and Rear

Front RockJock Antirock

Exterior

JCR Dagger Frame Chop Rear Bumper

Custom Fabricated front frame chop bumper

VKS weld-on Rock Sliders

TNT Customs Rear Corner Guard

Lighting

MaxBilt Rear Tail Lights

Drivetrain

2006 Ford Superduty Dana 60 Front Axle

Artec 3-link Truss

ARB Air Locker in Front

2002 Chevy 14 Bolt Rear Axle

Barnes 4WD Rear Truss

Detroit Locker in Rear

5.38 Gears

Adams Driveshafts Front & Rear 1350 Drive Shafts

Brakes

Powerstop Brakes Front and Rear

Mopar J8 Master Cylinder and Brake Booster

Engine

3.8L V6

Exhaust

Magnaflow Resonator

Interior

PRP 4.2 Harnesses

Rockhard 4x4 Harness Bar

PRP Seat Covers

Other

Badlands Apex 12k lbs winch

ARB Single High Output Air Compressor

PSC Hydro Assist

Artec High Steer Weld-on Arms

Artec Superduty Steering
